It is a PLC control floral foam cutting machine
The whole cutting line is composed as follows:
A Belt Conveyor (1) 2500mm length, 1200 width for floral foam Block
transporing
after cutting. It is driven by an AC motor. It has two pneumatic holding systems.
A mobile horizontal cutting station (2) for horizontal cutting. It
is used to cut the foam
block to requestd thickness which is 80mm. The whole horizontal
cutting frame is driven
by an AC motor which driven by an inverter.
A Belt Conveyor (3) 1800mm length, 1200 width for floral foam block
transport.
It keeps same speed and action with (1) belt conveyor.
A vertical cutting station (4) for vertical cutting. It can cut the
floral foam
boards 1450mm*1450mm*80mm to be 1450mm*230mm*80mm and trimming two
sides.
It has the de-dust system to take the dust during cutting away.
A Belt Conveyor (5) 1800mm length, 1500 width for floral foam block
transport.
It is driven by an AC motor.
A vertical cutting station (6) for vertical cutting. It can cut the
floral foam boards
1450mm*230mm*80mm to be 110mm*230mm*80mm and trimming two sides.
It has the de-dust system to take the dust during cutting away.
A pneumatic marking system (7) for stamp marks on the final
product.
It can press down with logo molds automatic.
A Belt Conveyor (8) for final product which size is
110mm*230mm*80mm tranport out.
Packing:
For the packing, there are a professional team to loading the
cargo. and also,
we have some long-term cooperation with the shipping agent who is
rich experience
of carrier. So do not worry, it can save money and safe for you.
After-sale Service:
Our engineers is avilable to oversea for coordinate installation,
commissioning and training.
Cost for flight and suitable accommodation plus USD 60 per day each
person will be
charged additionally.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. 24 hours on line service each day, free technical support.
5. Machine has been adjusted and test before delivery.
Warranty: 12 months limited warranty starting from date of delivery excluding wear parts.
shipping cost for parts to be replaced during warranty period have
to be borned by the customers.
Terms of Paypent: 30% advance payment by T/T upon signing the contract
70% covered by Confirmed Irrevocable Sight L/C
Company Information
Fuyang D&T Industry CO., LTD. Specializes in manufacturing CNC
foam Cutting machine,
polyurethane cutting machine, quilting machine and foam relation
assistant equipments.
Through the research of our engineers, our cutting machine had
connected well with
the popularized CAD and achieved automation and high efficiency,
high accuracy and
makes it easy to operate.We always put the customer on the first place and
make utmost
efforts to satisfy you.We wholeheartedly look forward to developing economic,
technical and
trade cooperation with you.
Products: Fast wire cutting machine, pu cutting machine, hot wire
cutting machine, eps
cutting machine, quilting machine and so on.
